Bodine Electric Company
Pacesetter 42R-5N Right Angle 230 and 230/460 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Single Voltage 230 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2270 | 23 rpm | 121 lb-in | 3/8 | 75 | $785.68 | Add to Cart |
| 2271 | 43 rpm | 113 lb-in | 3/8 | 40 | $785.68 | Add to Cart |
| N2275 | 57 rpm | 109 lb-in | 3/8 | 30 | $785.68 | Add to Cart |
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2272 | 85 rpm | 103 lb-in | 3/8 | 20 | $785.68 | Add to Cart |
| 2273 | 170 rpm | 101 lb-in | 3/8 | 10 | $785.68 | Add to Cart |
| 2274 | 340 rpm | 54 lb-in | 3/8 | 5 | $785.68 | Add to Cart |
| 2870 | 23 rpm | 121 lb-in | 3/8 | 75 | $840.33 | Add to Cart |
| 2871 | 43 rpm | 113 lb-in | 3/8 | 40 | $840.33 | Add to Cart |
| 2872 | 85 rpm | 103 lb-in | 3/8 | 20 | $840.33 | Add to Cart |
| 2873 | 170 rpm | 101 lb-in | 3/8 | 10 | $840.33 | Add to Cart |
| 2874 | 340 rpm | 54 lb-in | 3/8 | 5 | $840.33 | Add to Cart |
| 2875 | 57 rpm | 109 lb-in | 3/8 | 30 | $840.33 | Add to Cart |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | $38.94 | Add to Cart |
| 0985 | Die cast oversized terminal box kit | $78.13 | Add to Cart |
| 1984 | Die cast metric standard terminal box kit | $56.02 | Add to Cart |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
