Bodine Electric Company
42R-FX Parallel Shaft 115 VAC Split Phase Gearmotors
Single Speed, continuous duty rated.
Split phase gearmotors are designed for 5-6 starts and stops per hour (max). For more frequent start and stop applications, select capacitor gearmotors.
Motors can operate on 115 VAC, 60Hz only.
Totally enclosed, fan cooled IP-20 rating. IP-44 with optional t-box kit installed.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
| Model Number | Speed (rpm) | Torque | Motor Output Power (hp) | Gear Ratio | Price | |
|---|---|---|---|---|---|---|
| 0649 | 340 | 28 lb-in | 1/6 | 5 | $554.76 | Add to Cart |
| 0650 | 340 | 53 lb-in | 1/6 | 10 | $554.76 | Add to Cart |
| 0651 | 340 | 80 lb-in | 1/6 | 15 | $554.76 | Add to Cart |
| 0652 | 170 | 107 lb-in | 1/6 | 20 | $614.88 | Add to Cart |
| 0653 | 115 | 160 lb-in | 1/6 | 30 | $614.88 | Add to Cart |
| 0654 | 85 | 214 lb-in | 1/6 | 40 | $614.88 | Add to Cart |
| 0655 | 57 | 321 lb-in | 1/6 | 60 | $614.88 | Add to Cart |
| 5635 | 28 | 350 lb-in | 1/6 | 90 | $668.26 | Add to Cart |
| 5636 | 14 | 350 lb-in | 1/6 | 120 | $668.26 | Add to Cart |
| 5637 | 9 | 350 lb-in | 1/6 | 180 | $668.26 | Add to Cart |
| 5639 | 6 | 350 lb-in | 1/6 | 300 | $668.26 | Add to Cart |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | $38.94 | Add to Cart |
| 0969 | "L" Bracket kit for base, ceiling, and sidewall mounting | $45.05 | Add to Cart |
