Bodine Electric Company
Pacesetter 48R-5H Right Angle 230/460 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products.
Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed.
We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| N2280 | 35 rpm | 296 lb-in | 3/4 | 48 | $1095.85 | Add to Cart |
| 2281 | 47 rpm | 285 lb-in | 3/4 | 36 | $1095.85 | Add to Cart |
| N2282 | 94 rpm | 256 lb-in | 3/4 | 18 | $1095.85 | Add to Cart |
| N2283 | 170 rpm | 178 lb-in | 3/4 | 10 | $1095.85 | Add to Cart |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | $38.94 | Add to Cart |
| 0985 | Die cast oversized terminal box kit | $78.13 | Add to Cart |
| 1984 | Die cast metric standard terminal box kit | $56.02 | Add to Cart |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
